Tune 15mm axle for King hubs


Tune 15mm axle

Quick facts:

  • weighs 18g;
  • uses shims for bearing preload (like 9mm QR axle).

Installation

  • use a skewer or suitable rod to knock out one of the 9mm QR end caps from the other side;
  • remove 9mm QR axle;
  • remove one end cap from 15mm axle;
  • insert into hub;
  • replace 15mm axle end cap.
